Technical Data
Properties | Unit | Value |
Density | g/cm3 | 3.2 |
Flexural Strength | N/mm2 | 730 |
Compressive Strength | N/mm2 | 2550 |
Coeff. of Thermal Expansion | 10-6 K-1 | 3.5 |
Thermal Conductivity | W/mK | 21 |
Continuous Use Temperature | °C | 1300 |
Maximum Use Temperature | °C | 1300 |
Vickers Hardness | HV0.5 | 1620 |
Modulus of Elasticity (young) | GPa | 330 |
Impact Resistance | MPa m1/2 | 6.8 |
Weibull Modulus | m | 14 |
Thermal Shock Resistance | ΔT °C | 730 |
Volume Resistivity at 20 °C | Ωcm | >1011 |
All information in this data sheet is given in good faith and represents our latest knowledge. The values above are typical test results from short time tests and should not be taken as guaranteed, for specifications or primary selection of materials.
Keeprecision
-1300-GR is a registered trade-mark from Keeprecision Thermal Insulation Materials Co., Ltd.
Denotation
Brand Name — Long-term Application Temperature — Color
Ex. Keeprecision - 200 - GN refers to Keeprecision
green thermal insulation materials with the application
temperature 200°C.
Note: There is an additional letter "T" in the color term to distinguish between products of
the same long-term application temperature and color, but different composition.
Long-term application temperature(°C):110,120, 180, 200, 210, 220, 250, 280, 350,
500, 600, 700, 800,1000,1100,1200
Capitals to denote the color: WH(white) O YE(yellow) O GN(green) O BL(black)
O BU(blue) O SL(silver) O GR (gray) O BR(brown) O GD(gold) O RD(red)
